An Enquiry Of Enameled Wires From Austria Merchant

Date: Sep 20, 2023

Recently, Austria merchant has an enquiry the follow enameled wires:

The 180°C enamelled round aluminum wires based on IEC 60317-15 standard technical characteristics are as follows:

• Resistance to high temperatures (according to thermal class);
• Appropriate mechanical strength for winding processes;
• Resistance to insulating epoxy resins;
• Isolation capability as specified;
• Dimensional limits as specified.
Yeah, LP enameled wires can achieve the requirement.

SAP Part Number:	AWG	Ø Aluminum conductor Min.-[mm]	Ø Enamelled Wire Máx.- [mm]	Breakdown Voltage Mín. (*)
A7B91503823388	10	2.563	2.743	12 KV
A7B91503823358	11	2.281	2.461
A7B91503817883	12	2.032	2.205
A7B91503820303	13	1.811	1.976
A7B91503817149	14	1.613	1.773
A7B91503814346	15	1.435	1.588
A7B91503817147	16	1.278	1.422
A7B91503816478	17	1.138	1.275
A7B91503822892	18	1.013	1.143
A7B91503817148	19		1.026
A7B91503822893	20		0.922

If you have any questions about enameled wires, welcome to LP Industry.
